TB50 Multimedia Player / Controller for LED
NovaStar TB50 is an advanced LED multimedia player meticulously designed by Nova for LED displays. It seamlessly integrates playback and transmission capabilities. When coupled with our cloud-based publishing and monitoring platforms, the TB50 provides users with the flexibility to efficiently manage LED screens from any Internet-connected device, regardless of their location or the time.
- Impressive Loading Capacity: Supports up to 1,300,000 pixels for stunning visuals.
- Enhanced Connectivity: Features 2x Gigabit Ethernet ports for reliable connections.
- Audio Excellence: Provides 1x Stereo audio connector for an enriched audiovisual experience.
- Video Output: Includes 1x HDMI 1.4 connector for high-quality video output.
- USB Compatibility: Equipped with 1x USB 3.0 (Type A) port, allowing playback of content imported from a USB drive and firmware upgrades.
- Versatile USB Port: Offers 1x USB (Type B) port for additional functionality.
- Network Connection: Provides 1x Gigabit Ethernet port for connecting to LAN, public networks, or computers for content publishing and screen control.”
| Electrical Parameters | Input Power | 100-240V~, 50/60Hz, 0.6A |
| Maximum power consumption | 18 W | |
| Storage Space | RAM | 1 GB |
| Internal storage space | 16 GB | |
| Temperature | -40ºC –80ºC | |
| Humidity | 0% RH–80% RH, non-condensing | |
| Temperature | -20ºC to +60ºC | |
| Humidity | 0% RH to 80% RH, non-condensing | |
| Dimensions (L×W×H) | 385.0 mm × 280.0 mm × 75.0 mm | |
| List |
1x TB60 1x Wi-Fi omnidirectional antenna 1x AC power cord 1x Quick Start Guide |
|
| Dimensions (H × W × D) |
274.3 mm × 139.0 mm × 40.0 mm | |
| Net Weight | 1230.4 g | |
| IP Rating |
IP20 Please prevent the product from water intrusion and do not wet or wash the product |
|
| System Software |
Android 11.0 operating system software Android terminal application software FPGA program Note: Third-party applications are not supported. |
