XR COB Series
Jona Led’s premium line of XR COB series tiny LED displays will captivate your senses with an immense experience. Driven by micro technology, these very thin pixel pitch screens mesmerize audiences with vivid HDR10 picture quality, up to 16K resolution, and a high contrast ratio of 15000:1.
These displays are best for digital transformation as each of these is calibrated and has presets for HDR color grading.
(Pixels: P0.4, 0.8, 1.2, 1.5, 1.8 & 1.9 mm)
- Efficient Technical Design
- Vibrant, Lifelike colors
- High Contrast Ratio
- High Brightness
- Zero Disruptions
- Low Power Consumption
- Anti-Collision
| Pixel Pitch (mm) | 0.9375 | 1.25 | 1.56 | 1.87 |
| LED Type | Flip Chip COB Common -Cathode | |||
| Pixel Configuration | 3 In 1 | |||
| Pixel Density(Pixels/m2) | 1,137,778 | 6,400,00 | 6,400,00 | 409,600 284,444 |
| Brightness | 500-1200 cd/m2 | |||
| Scan Rate | 1/60 | 1/45 | 1/48 | 1/30 |
| Refresh Rate | >3840 | |||
| Cabinet Resolution(W*H) | 640*360 | 480*270 | 384*216 | 320*180 |
| Cabinet size(mm) | Die casting aluminum cabinet 600 x 337.5 x 32.5mm | |||
| Module size (mm) | 150*168.75 | |||
| Weight | 7.5KG | |||
| Maintenance Method | Front | |||
| Horizontal/Vertical Viewing Angle | 170 / 170 | |||
| Grey Scale | 14-16 | |||
| Color Temp. | 3200-9300 | |||
| Contrast Ratio | >10,000:1 | |||
| Input Signal | HDMI, DVI/VGA, RGBHV Composite, S- VIDEO,YPbPr(HDTV)etc… | |||
| Dot to Dot Calibration | YES | |||
| Brightness Calibration | YES | |||
| Module Power Supply Voltage DC | DC2.8V+3.8V | |||
| Max Power Consumption | <300 | |||
| Avg. Power Consumption | <100 | |||
| Display Colors | 14 Bit | |||
| HDR Support | HDR 10 OR HDR 10+ | |||
| Run Time | 24*7 | |||
| Certification | BIS & ISO | |||
| LED Life Time | 100000 Hours | |||
LED displays are revolutionizing the way businesses operate and sold in today’s dynamic landscape
Quick and multi-angle mounting is made possible by excellent mechanical design, which also guarantees a gap-free, uniform screen surface.
The fine pixel pitch panels have power systems and backup data, which minimizes the possibility of total failure and screen blackout.
The Flip Chip technology disperses heat through the common cathode; enhancing electrical performance, thermal control, pixel density, and color constancy.
The indoor LED display fills the inside space with plenty of visual stimulation despite its thin 30mm thickness and light 3.20kg weight.
Each indoor XR Chip-On-Board display is moisture-proof, anti-static, dust-proof, anti-oxidized, and highly reliable.
Your LED display ought to appear picture-perfect at all times. You can effortlessly create a seamless canvas with the Jona Led screens
Jona Led has developed components like power-saving ICs & lamps, unique PCBs, and efficient power supplies that guarantee lower power consumption than average
Greater stability and a smooth transition between display and video images are what we guarantee
